One of the most important and fundamental elements in design and execution of pipeline is to create pipeline routes and right of ways in order to facilitate side booms traffic, accessibility to different sections of pipeline and also provide proper circumstances to gather executive stuffs. Current training booklet has been published to hold the aim of familiarity with principles and fundamentals of pipeline route and right of way design with the approach of Plan & Profile drawings preparation which are one of the most important and comprehensive documents in pipeline design
process by practical use of civil 3D software.
